Java JDK 镜像构建

Java 镜像构建|JDK 镜像构建

yzx  收录于  类别 Java
   约 2660 字  预计阅读 6 分钟
Java JDK 镜像构建|JDK 镜像构建

Java镜像构建

Java 应用程序容器化运行推荐使用 OpenJDK 镜像作为 Java 运行镜像。

推荐 OpenJDK 镜像有两个：

  1. OpenJDK 官方镜像：openjdk:17-jdk 【标准镜像 (~300MB)】 / openjdk:17-jdk-slim 【Slim镜像 (~150MB) - 移除文档、调试工具等】，都是基于 debian bullseye （11） 系统
  2. Eclipse Temurin（原 AdoptOpenJDK）是目前最受欢迎的 OpenJDK 发行版之一 【推荐】 ：eclipse-temurin:17-jdk-jammy （基于 Ubuntu 22.04）

OpenJDK 官方镜像 Dockerfile 编写，添加运行工具和系统定制。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

FROM openjdk:8-jdk-slim

# openjdk:17-jdk         # 完整版(基于Debian)
# openjdk:17-jdk-slim    # 精简版(基于Debian Slim)

# openjdk:8-jdk -> debain 11(bullseye)
# openjdk:11-jdk -> debain 11(bullseye)
# openjdk:17-jdk -> debain 11(bullseye)

COPY ./debian11.sources /etc/apt/sources.list.d/debian.sources

RUN cp /etc/apt/sources.list /etc/apt/sources.list.backup \
    && echo "" > /etc/apt/sources.list \
    && apt-get update -y \
    && apt-get install -y curl vim iputils-ping locales procps htop telnet tzdata \
    && sed -i 's/# zh_CN.UTF-8 UTF-8/zh_CN.UTF-8 UTF-8/ ; s/# en_US.UTF-8 UTF-8/en_US.UTF-8 UTF-8/' /etc/locale.gen \
    && locale-gen \
    && ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
    && apt-get clean \
    && rm -rf /var/lib/apt/lists/*

ENV TERM=xterm
ENV TZ=Asia/Shanghai
ENV LANG=en_US.UTF-8

WORKDIR /opt/

CMD ["java", "-version"]

Debian 11 （bullseye）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian
Suites: bullseye bullseye-updates
Components: main contrib non-free
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian-security
Suites: bullseye-security
Components: main contrib non-free
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

Debian 12 （bookworm）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian
Suites: bookworm bookworm-updates
Components: main contrib non-free non-free-firmware
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian-security
Suites: bookworm-security
Components: main contrib non-free non-free-firmware
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

Eclipse Temurin 是目前最受欢迎的 OpenJDK 发行版之一

  • 完全满足企业级 Java 应用的所有需求
  • 在性能、稳定性和安全性上表现优异
  • 拥有活跃的社区支持和商业可选服务

Eclipse Temurin 镜像 Dockerfile：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

FROM eclipse-temurin:8-jdk-jammy

# ubuntu 24.04 (Noble) ; ubuntu 22.04 (Jammy) ; ubuntu 20.04 (Focal) ; ubuntu 18.04 (Bionic)
# eclipse-temurin:17-jdk-noble / eclipse-temurin:17-jdk-jammy /

RUN apt-get update -y \
    && apt-get install -y --no-install-recommends curl vim iputils-ping locales procps htop telnet tzdata \
    && sed -i 's/# zh_CN.UTF-8 UTF-8/zh_CN.UTF-8 UTF-8/ ; s/# en_US.UTF-8 UTF-8/en_US.UTF-8 UTF-8/' /etc/locale.gen \
    && locale-gen \
    && ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
    && apt-get clean \
    && rm -rf /var/lib/apt/lists/*

ENV TERM=xterm
ENV TZ=Asia/Shanghai
ENV LANG=en_US.UTF-8

WORKDIR /opt/

CMD ["java", "-version"]

基于 Debian 镜像手动构建 Oracle JDK 镜像 Dockerfile：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

FROM debian:12.10

COPY ./sources.list /etc/apt/sources.list.d/debian.sources

RUN apt-get update -y \
    && apt-get install -y curl vim iputils-ping locales procps htop telnet tzdata \
    && sed -i 's/# zh_CN.UTF-8 UTF-8/zh_CN.UTF-8 UTF-8/ ; s/# en_US.UTF-8 UTF-8/en_US.UTF-8 UTF-8/' /etc/locale.gen \
    && locale-gen \
    && ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
    && apt-get clean \
    && rm -rf /var/lib/apt/lists/*

ADD jdk-8u431-linux-x64.tar.gz /usr/local/src/

ENV TERM=xterm
ENV TZ=Asia/Shanghai
ENV LANG=en_US.UTF-8
ENV JAVA_VERSION=8u431
ENV JAVA_HOME=/usr/local/src/jdk1.8.0_431
ENV CLASSPATH=.:${JAVA_HOME}/lib/dt.jar:${JAVA_HOME}/lib/tools.jar:${JAVA_HOME}/jre/lib/rt.jar
ENV PATH=${PATH}:${JAVA_HOME}/bin

WORKDIR /opt/

CMD ["java", "-version"]

debian 12（bookworm） 软件源 sources.list

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian
Suites: bookworm bookworm-updates
Components: main contrib non-free non-free-firmware
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

Types: deb
URIs: http://mirrors.ustc.edu.cn/debian-security
Suites: bookworm-security
Components: main contrib non-free non-free-firmware
Signed-By: /usr/share/keyrings/debian-archive-keyring.gpg

基于 CentOS7 镜像构建 Oracle JDK 的 Dockerfile：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

FROM centos:7.9.2009

COPY ./Centos7.repo /opt/CentOS-Base.repo

RUN ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
    && mkdir -p /etc/yum.repos.d/backup \
    && mv /etc/yum.repos.d/*.repo /etc/yum.repos.d/backup/ \
    && mv /opt/CentOS-Base.repo /etc/yum.repos.d/CentOS-Base.repo \
    && yum clean all \
    && yum makecache \
    && yum install -y curl wget telnet vim \
    && yum clean all

ADD jdk-8u431-linux-x64.tar.gz /usr/local/src/

ENV TZ=Asia/Shanghai
ENV LANG=en_US.UTF-8
ENV JAVA_VERSION=8u431
ENV JAVA_HOME=/usr/local/src/jdk1.8.0_431
ENV CLASSPATH=.:${JAVA_HOME}/lib/dt.jar:${JAVA_HOME}/lib/tools.jar:${JAVA_HOME}/jre/lib/rt.jar
ENV PATH=${PATH}:${JAVA_HOME}/bin

WORKDIR /opt/

CMD ["java", "-version"]

CentOS7 软件镜像源 Centos7.repo

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

[base]
name=CentOS-$releasever - Base - mirrors.aliyun.com
failovermethod=priority
baseurl=http://mirrors.aliyun.com/centos/$releasever/os/$basearch/
gpgcheck=1
gpgkey=http://mirrors.aliyun.com/centos/RPM-GPG-KEY-CentOS-7

#released updates
[updates]
name=CentOS-$releasever - Updates - mirrors.aliyun.com
failovermethod=priority
baseurl=http://mirrors.aliyun.com/centos/$releasever/updates/$basearch/
gpgcheck=1
gpgkey=http://mirrors.aliyun.com/centos/RPM-GPG-KEY-CentOS-7

#additional packages that may be useful
[extras]
name=CentOS-$releasever - Extras - mirrors.aliyun.com
failovermethod=priority
baseurl=http://mirrors.aliyun.com/centos/$releasever/extras/$basearch/
gpgcheck=1
gpgkey=http://mirrors.aliyun.com/centos/RPM-GPG-KEY-CentOS-7

#additional packages that extend functionality of existing packages
[centosplus]
name=CentOS-$releasever - Plus - mirrors.aliyun.com
failovermethod=priority
baseurl=http://mirrors.aliyun.com/centos/$releasever/centosplus/$basearch/
gpgcheck=1
enabled=0
gpgkey=http://mirrors.aliyun.com/centos/RPM-GPG-KEY-CentOS-7

#contrib - packages by Centos Users
[contrib]
name=CentOS-$releasever - Contrib - mirrors.aliyun.com
failovermethod=priority
baseurl=http://mirrors.aliyun.com/centos/$releasever/contrib/$basearch/
gpgcheck=1
enabled=0
gpgkey=http://mirrors.aliyun.com/centos/RPM-GPG-KEY-CentOS-7

Java 应用运行镜像 Dockerfile 文件：

1
2
3
4
5

FROM jdk8-8u431-debian-1210:v1
WORKDIR /opt/
COPY app.jar /opt/app.jar
COPY entrypoint.sh /opt/
ENTRYPOINT ["bash","/opt/entrypoint.sh"]

jdk 1.8 应用运行 entrypoint 脚本：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

#!/bin/bash
SCRIPT_DIR=$(cd $(dirname $0); pwd)
echo "execution dir [${SCRIPT_DIR}}]" | tee -a startup.log
cd ${SCRIPT_DIR}

ncpu=$(nproc)
ConcGCThreads=$(expr $ncpu / 4)
ConcGCThreads=$(( $ConcGCThreads > 1 ? $ConcGCThreads : 1 ))
echo "cpu [${ncpu}] nthread [${ConcGCThreads}]"

# https://blog.gceasy.io/java-cms-gc-tuning/

MEM_OPTS=${MEM_OPTS:-"-XX:InitialRAMPercentage=90.0 -XX:MaxRAMPercentage=90.0 -XX:MetaspaceSize=128m -XX:MaxMetaspaceSize=128m"}
GC_OPTS=${GC_OPTS:-"-XX:+UseConcMarkSweepGC -XX:+UseParNewGC"}
# -XX:NewRatio=1
JVM_OPTS=${JVM_OPTS:-"-XX:CMSInitiatingOccupancyFraction=75 -XX:+UseCMSInitiatingOccupancyOnly -XX:+CMSScavengeBeforeRemark -XX:ParallelGCThreads=$(nproc) -XX:ConcGCThreads=${ConcGCThreads} -XX:+ScavengeBeforeFullGC -XX:+CMSParallelRemarkEnabled -XX:+UseCMSCompactAtFullCollection -XX:CMSFullGCsBeforeCompaction=0"}
OTHER_OPTS=${OTHER_OPTS:-""}

# -XX:CMSInitiatingOccupancyFraction=75 -XX:+UseCMSInitiatingOccupancyOnly # 限制只在老年代达到 75% 才回收
# -XX:+CMSScavengeBeforeRemark # 在重新标记前执行 Young GC
# -XX:+UseCMSCompactAtFullCollection -XX:CMSFullGCsBeforeCompaction=0 # 启用 Full GC 压缩，避免 Full GC 后内存碎片，第一个参数是开启这个能力，第二个参数表示在压缩

# -XX:+CMSClassUnloadingEnabled           # 启用类卸载
# -XX:+ExplicitGCInvokesConcurrent        # System.gc() 时使用 CMS 而非 Full GC
# -XX:+CMSParallelInitialMarkEnabled      # 初始标记阶段并行化
# -XX:+CMSParallelRemarkEnabled           # 重新标记阶段并行化

# JMX -> JMC
JMX_OPTS="-XX:+UnlockCommercialFeatures -XX:+FlightRecorder -Dcom.sun.management.jmxremote -Dcom.sun.management.jmxremote.port=7091 -Dcom.sun.management.jmxremote.ssl=false -Dcom.sun.management.jmxremote.authenticate=false"

echo "JVM MEM_OPTS [${MEM_OPTS}]" | tee -a startup.log
echo "JVM GC_OPTS [${GC_OPTS}]" | tee -a startup.log
echo "JVM JVM_OPTS [${JVM_OPTS}]" | tee -a startup.log
echo "JVM OTHER_OPTS [${OTHER_OPTS}]" | tee -a startup.log

EXEC_CMD="java \
${MEM_OPTS} \
${GC_OPTS} \
${JVM_OPTS} \
${OTHER_OPTS} \
-XX:+HeapDumpOnOutOfMemoryError -XX:+CrashOnOutOfMemoryError -XX:HeapDumpPath=${SCRIPT_DIR}/logs/heapdump_%p_%t.hprof \
-XX:+PrintGCDetails -XX:+PrintGCDateStamps -Xloggc:${SCRIPT_DIR}/logs/gc-%t.log \
-XX:+UseGCLogFileRotation -XX:NumberOfGCLogFiles=10 -XX:GCLogFileSize=50m \
-jar ${SCRIPT_DIR}/app.jar"

echo "exec [${EXEC_CMD}]" | tee -a startup.log
mkdir -p ${SCRIPT_DIR}/logs/
exec ${EXEC_CMD}

jdk 11 及以上版本运行脚本：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61

#!/bin/bash
SCRIPT_DIR=$(cd $(dirname $0); pwd)
echo "execution dir [${SCRIPT_DIR}}]" | tee -a startup.log
cd ${SCRIPT_DIR}

ncpu=$(nproc)
ConcGCThreads=$(expr $ncpu / 4)
ConcGCThreads=$(( $ConcGCThreads > 1 ? $ConcGCThreads : 1 ))
echo "cpu [${ncpu}] nthread [${ConcGCThreads}]" | tee -a startup.log

# https://blog.gceasy.io/simple-effective-g1-gc-tuning-tips/
# -XX:+UseStringDeduplication

MEM_OPTS=${MEM_OPTS:-"-XX:+UseContainerSupport -XX:InitialRAMPercentage=90.0 -XX:MaxRAMPercentage=90.0 -XX:MetaspaceSize=128m -XX:MaxMetaspaceSize=128m"}
GC_OPTS=${GC_OPTS:-"-XX:+UseG1GC"}
# 默认低延迟配置，小堆(<4G)：1-2m / 中堆(4-32G)：4m / 大堆(>32G)：8m
JVM_OPTS=${JVM_OPTS:-"-XX:G1HeapRegionSize=4m -XX:MaxGCPauseMillis=200 -XX:InitiatingHeapOccupancyPercent=45  -XX:G1ReservePercent=10 -XX:ParallelGCThreads=$(nproc) -XX:ConcGCThreads=${ConcGCThreads} -XX:+UseStringDeduplication"}
OTHER_OPTS=${OTHER_OPTS:-""}

# -XX:G1ReservePercent=10 # 10-15%（默认值）指定了堆内存中应保留作为"空闲空间"的比例，主要作为 GC 过程中的临时内存缓冲区，确保有足够空间用于对象晋升（从年轻代到老年代）
# -XX:+PerfDisableSharedMem # 禁用 JVM 在共享内存中存储性能统计数据的机制

# -XX:ParallelGCThreads=8 # 并行GC线程数（建议等于CPU核心数）
# -XX:ConcGCThreads=2 # 并发标记线程数（通常为ParallelGCThreads的1/4）
# -XX:+ParallelRefProcEnabled # 开启并行引用处理

# -XX:G1NewSizePercent=20 # 年轻代初始占比（默认堆的5%）
# -XX:G1MaxNewSizePercent=60 # 年轻代最大占比（默认60%）[降低最大占比（减少GC停顿）]
# Error: VM option 'G1NewSizePercent' is experimental and must be enabled via -XX:+UnlockExperimentalVMOptions

# -XX:MetaspaceSize=256m -XX:MaxMetaspaceSize=512m # 元空间大小设置
#-XX:MaxDirectMemorySize=1g # 堆外内存限制（如果使用NIO等）

# -XX:InitiatingHeapOccupancyPercent=45 # 启动并发标记的堆占用率阈值（默认45%），老年代占用率达到此百分比时启动并发标记

# -XX:G1MixedGCLiveThresholdPercent=85 # 混合回收阈值，Region 中存活对象占比超过此值则不回收
# Error: VM option 'G1MixedGCLiveThresholdPercent' is experimental and must be enabled via -XX:+UnlockExperimentalVMOptions.

# JFR飞行记录（JDK11商业特性）
# -XX:StartFlightRecording=duration=60s,stackdepth=128,settings=profile,filename=recording.jfr

# JDK 11+需要显式启用JFR
JMX_OPTS="-XX:+FlightRecorder -XX:StartFlightRecording=disk=true,filename=${SCRIPT_DIR}/recording.jfr,maxsize=1024m,maxage=1d -Dcom.sun.management.jmxremote -Dcom.sun.management.jmxremote.port=7091 -Dcom.sun.management.jmxremote.ssl=false -Dcom.sun.management.jmxremote.authenticate=false"

echo "JVM MEM_OPTS [${MEM_OPTS}]" | tee -a startup.log
echo "JVM GC_OPTS [${GC_OPTS}]" | tee -a startup.log
echo "JVM JVM_OPTS [${JVM_OPTS}]" | tee -a startup.log
echo "JVM OTHER_OPTS [${OTHER_OPTS}]" | tee -a startup.log

EXEC_CMD="java \
${MEM_OPTS} \
${GC_OPTS} \
${JVM_OPTS} \
${OTHER_OPTS} \
-XX:+HeapDumpOnOutOfMemoryError -XX:+CrashOnOutOfMemoryError -XX:HeapDumpPath=${SCRIPT_DIR}/logs/heapdump_%p_%t.hprof \
-Xlog:gc*=info:file=${SCRIPT_DIR}/logs/gc-%t.log:time,uptime,level,tid,tags:filecount=10,filesize=50M \
-jar ${SCRIPT_DIR}/app.jar"

echo "exec [${EXEC_CMD}]" | tee -a startup.log
mkdir -p ${SCRIPT_DIR}/logs/
exec ${EXEC_CMD}

线程栈分析：

Java 线程堆栈分析工具 （IBM Thread and Monitor Dump Analyzer for Java (TMDA)）

  1. 某个 Java 进程中最耗费 CPU 的 Java 线程 : ps -ef | grep mrf-center | grep -v grep
  2. 线程 id 转 16 进制： printf "%x\n" <pid>
  3. jstack 找出占用线程：jstack <pid> | grep 54ee
1
2

# 线程栈
jstack -l <pid> > jdk-stack.txt

堆内存分析：

Java 内存 dump 分析工具 (Memory Analyzer (MAT))

1
2
3

$ jmap -dump:format=b,file=heap.hprof <pid>

jmap -dump:[live,]format=b,file=jmap.bin <pid>
  • live 参数是可选的，如果指定，则只转储堆中的活动对象；如果没有指定，则转储堆中的所有对象。
  • format=b 表示以hprof二进制格式转储Java堆的内存。
  • file=<filename> 用于指定快照dump文件的文件名。

内存监控工具：

1
2
3

# 格式：jstat [option]  lvmid  interval  count
$ jstat -gc <pid> 250 20
# 每 250 毫秒查询一次进程垃圾收集状况，一共查询 20 次

jcmd (推荐)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

# 列出所有 Java 进程
jcmd -l

# 查看特定进程的内存使用（替换 <pid>）
jcmd <pid> VM.native_memory
jcmd <pid> GC.heap_info
jcmd <pid> VM.info

# 显示堆内存摘要
jmap -heap <pid>

# 生成堆转储文件（谨慎使用，生产环境可能影响性能）
jmap -dump:live,format=b,file=heap.hprof <pid>

jhsdb 使用

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

# Java 运行信息
jhsdb jinfo --pid <PID>
# Java 运行栈
jhsdb jstack --pid <PID>
# Java 堆内存信息
jhsdb jmap --heap --pid <PID>

# 生成线程转储
jhsdb jstack --pid <PID> > thread_dump.txt
# 带锁信息
jhsdb jstack --locks --pid <PID>

# 详细堆信息
jhsdb jmap --heap --pid <PID>
# 生成堆转储
jhsdb jmap --binaryheap --pid <PID> --file heap.bin
# 堆内存直方图
jhsdb jmap --histo --pid <PID>

# 查看所有系统属性
jhsdb jinfo --sysprops --pid <PID>
# 查看所有 JVM 标志
jhsdb jinfo --flags --pid <PID>

相关内容

Java JDK 镜像构建|JDK 镜像构建

Spring Boot 自定义类加载器

Java JDK 镜像构建|JDK 镜像构建

Java程序运行镜像构建

Java JDK 镜像构建|JDK 镜像构建

jdk 镜像推荐构建

Java JDK 镜像构建|JDK 镜像构建

Java资源解析

Java JDK 镜像构建|JDK 镜像构建

Java日期时间计算

更新于 2025年08月18日
阅读原始文档
 Java, containerd
返回 | 主页
